5,201 Reply by wb0s

(178 replies, posted in Track)

Thanks Rico....I can see 'em runnin' already!!!!

Go to forum: Track

5,202 Reply by wb0s

(178 replies, posted in Track)

Yes, it smooths it somewhat as it lays it down. After the tool lays it down you need to go back over it. I used a Bic type lighter like Luf says to burnish the tape.

I laid 336 feet of tape today. Two of the three lanes are taped.

http://www.naste.org/members/bill/IMG_0724.jpg

Go to forum: Track

5,203 Reply by wb0s

(178 replies, posted in Track)

Track builders, if you use copper tape on your tracks and you have not picked up one of Luf's track taping tools, DO IT before you build your next track! This tool is amazing and simple! I wish I would have found it years ago! I just laid down 40 feet of tape in less than 5 minutes! If this tool cost 5 times what he sells them for I'd still buy it!!!!   --------------------Bill

http://www.naste.org/members/bill/IMG_0722.jpg

Go to forum: Track

5,204 Reply by wb0s

(178 replies, posted in Track)

Correct, the alligator clips connect to the tubing's edge or rim. The inside diameter of the tubing is 1/2 inch so no, the standard electrical type plugs or banana plugs will not fit. The hook ups will be alligator clips only.

Just finished making up all the L shaped pieces of copper rod to use as the conductors from the tape to the wiring, all 42 of them!

Go to forum: Track

5,205 Reply by wb0s

(178 replies, posted in Track)

Today I built the driver's stations/controller hook-ups. Photos 203 through 222 in the "Slot-Tech" section under "NEW track at TooBad Motorplex" show how I built the controller hook-ups.   -----Bill

http://www.naste.org/members/bill/IMG_0719.jpg

Go to forum: Track

5,206 Reply by wb0s

(178 replies, posted in Track)

Beau, This will be a no glue track. The other 1/32 routed tracks that I have raced on have had very good luck with rubber tires, and no glue once the track is rubber'd up. NSR makes rubber tires in various compounds, the two softer compounds work very well on wood routed tracks. Some of the softer Slot.It tires work well, and so do urethane tires, so there are a lot of tire choices for use without glue. I will probably discourage the use of silicone tires as they tend to remove the rubber build up from the track surface, which hurts the effectiveness of the softer rubber compound tires. if I were setting up a scratchbuilt 1/32 car, I'd go with the softest NSR tires (I've had very good luck with them on Monte's track).    ---------------------Bill

Go to forum: Track

5,207 Reply by wb0s

(178 replies, posted in Track)

Thank you Beau. It's been a LONG process, but I have not been in any hurry. At this point I am pretty much on schedule for my goal to have it up and running by November 1 (that's 2011....for REAL!!!). I should be copper tapin' within the next week or so!!! I now have you on my official invitee list for the track break-in ceremony!!!    ------------------Bill

Go to forum: Track

5,208 Reply by wb0s

(178 replies, posted in Track)

I finished up the prep work for the power taps tonight. The track surface has been readied for all four power taps and the lap counter dead strip.

Here is what the completed dead strip area looks like with power tap provisions on either side:

http://www.naste.org/members/bill/IMG_0688.jpg

Go to forum: Track

5,209 Reply by wb0s

(178 replies, posted in Track)

I have updated the photos and description (152 through 202) of the build up of this track.  If you are interested in seeing more of the process click on the "Slot-Tech" tab on the NASTE Home Page, and then look in the  "NEW routed track at TooBad Motorplex" gallery.   --------------------Bill

Go to forum: Track

5,210 Reply by wb0s

(178 replies, posted in Track)

I'm not sure if I'm actually progressing????...............I don't have a Halloween car done..................    --------------Bill

Go to forum: Track

5,211 Reply by wb0s

(178 replies, posted in Track)

Been "off track" or "side tracked" for awhile but back on it today. I started the work for the power taps today. With an 84 foot lap length I decided on power taps every 20 feet. In the early 80's I restored a 1/24 track built by Dave Smith of Salem. A friend of mine Hugh Ellsworth helped me with the track and designed this type of power tape for copper tape tracks. I have not seen any other style that to me works or looks better. This system is easy to install although it looks harder than it really is. Thanks again Hugh!   -------------------Bill

First I lay out where the tape will be in relation to the guide slot.

http://www.naste.org/members/bill/IMG_0675.jpg

Then I drill a hole on either side of the slot.

http://www.naste.org/members/bill/IMG_0676.jpg

Using my Dremel mounted in a router base attachment I route from the hole up next to the guide slot where the copper tape will lay.

http://www.naste.org/members/bill/IMG_0678.jpg

This is the "ditch" or recess I end up with from the hole up to approximately 1/8 inch from the guide slot.

http://www.naste.org/members/bill/IMG_0680.jpg

I use a piece of copper plated welding rod with a bend in the top portion as the conductor between the copper tape and the power supply.

http://www.naste.org/members/bill/IMG_0683.jpg

The copper rod extends through the hole below the track. The tape is laid below the horizontal bend in the rod so that when the rod is pulled down into the recess the tape is captured below the rod. I then apply solder to the rod and tape within the recess.

http://www.naste.org/members/bill/IMG_0684.jpg

So today I got one power tap done, and the lap counter dead strip section.

http://www.naste.org/members/bill/IMG_0687.jpg

Go to forum: Track

5,212 Reply by wb0s

(17 replies, posted in NASTE)

Photos from NASTE 2012 race number 2. Thank you Dorothy!!!

http://www.facebook.com/l/rAQDr3GO_AQBh … ?start=all

And video:


http://www.facebook.com/l/XAQHDCODFAQHm … IezyFZe-MM

http://www.facebook.com/l/yAQGcvEGNAQGG … TzMSKatqN4

Go to forum: NASTE

5,213 Reply by wb0s

(17 replies, posted in NASTE)

Monte & Victoria, Thank you again for another fantastic fun filled night of racing! Daine, Cailin, and I had a wonderful time! Cailin is pumped and ready to go to the NASTE Halloween Race! Our NASTE races have become top notch events, not just from a slot racing perspective, but just as much of a fun social event with friends where even new folks fit right in and can feel comfortable. I think what we have going on is very special, and I really enjoy being part of it. I have to give credit for our success to all of the NASTE host tracks and track owners!!!! Thank you all!!!   --------------------Bill

Go to forum: NASTE

5,214 Reply by wb0s

(2 replies, posted in Penguin Point Raceway)

I'll echo that.....Thank You Monte & Victoria!

I had a great time as usual at your place!!! Great friends, great racing, & great food (well it sure smelled great anyway!)!!!  -----------------------Bill

Go to forum: Penguin Point Raceway

5,215 Reply by wb0s

(63 replies, posted in Cars)

Yes it is............

I'm bringing this thing out today to test on your track................

Go to forum: Cars

5,216 Reply by wb0s

(17 replies, posted in Track)

I like the looks of the layout Drew. What radius are the tightest corners?

I tried to post a comment on your BLOG, but evidently I did something wrong. I did not see anything post?    -----------------Bill

Go to forum: Track

5,217 Reply by wb0s

(63 replies, posted in Cars)

The chassis is done.

http://www.naste.org/members/bill/IMG_0669.jpg

Finishing up the body mounts.........

http://www.naste.org/members/bill/IMG_0672.jpg

She's a little porky at 124 + grams.............

Go to forum: Cars

5,218 Reply by wb0s

(5 replies, posted in Cars)

Monte's First Sunday is coming up in 3 days so it's back to work on the Ninco Ferrari.

Here's the completed repair with the .055" wire brace in place.  I used JB Weld epoxy exclusively on this repair. We'll see how she holds up on Sunday.

http://www.naste.org/members/bill/IMG_0667.jpg

http://www.naste.org/members/bill/IMG_0668.jpg

Go to forum: Cars

5,219 Reply by wb0s

(63 replies, posted in Cars)

Latest spy photos............................VWomp????

http://www.naste.org/members/bill/IMG_0656.jpg

http://www.naste.org/members/bill/IMG_0657.jpg

Go to forum: Cars

5,220 Reply by wb0s

(19 replies, posted in Penguin Point Raceway)

It's looking really good Monte!!!!

Go to forum: Penguin Point Raceway

5,221 Reply by wb0s

(178 replies, posted in Track)

Over the weekend I got the side boards painted black. I Went over the running surface this evening to check for flaws. I felt the surface was a little too aggressive as far as texture, so I lightly block sanded it with 220 grit. I'm happy now........... Next steps are the installation of the power taps using flush mounted copper rod, and the driver's station hookups with flush mounted copper tubing.             -----------------Bill

http://www.naste.org/members/bill/IMG_0634.jpg

http://www.naste.org/members/bill/IMG_0635.jpg

Go to forum: Track

5,222 Reply by wb0s

(19 replies, posted in Penguin Point Raceway)

The track is looking really good Monte!!!! Very nice work!!!

Hey, are those batteries for POWER tools I see there?????!!!!!!    ------------------Bill

Go to forum: Penguin Point Raceway

5,223 Reply by wb0s

(17 replies, posted in NASTE)

Pictures from the first race of the NASTE 2012 season courtesy of Dorothy "The Hammer" Abbott. Thanks Dorothy!!!!   --------------Bill

http://www.facebook.com/l/2AQBz4jtBAQD1 … ?start=all

And some video: http://www.facebook.com/l/pAQAnWH9zAQD5 … F1MnbEI8W0

Go to forum: NASTE

5,224 Reply by wb0s

(178 replies, posted in Track)

This weekend I got the last of the white scenery areas painted with a base color (ok, just flat brown).  I also painted the sides of the track table black. Another coat of black and some light sanding to the running surface and I'm ready to apply the copper tape!!!!!   -----------------------Bill

Go to forum: Track

5,225 Reply by wb0s

(17 replies, posted in Track)

Looking forward to pictures and then a test session Drew!!!   --------------------Bill

Go to forum: Track
